Advantage Post weld heat treatment
Post Weld Heat Treatment Services ( PWHT ) is defined as one of heat treatments done after welding/machining to improve the Chemical mechanical properties of weldment / machined surfaces. In concept, PWHT covers many different potential treatments. However, in steel fabrication, most common procedure used is Stress Relieving.
Advantage Post weld heat treatment
Post Weld Heat Treatment Services ( PWHT ) is defined as one of heat treatments done after welding/machining to improve the Chemical mechanical properties of weldment / machined surfaces. In concept, PWHT covers many different potential treatments. However, in steel fabrication, most common procedure used is Stress Relieving.
i. Stress induced by welding
As a result of welding process used to join metals together. The base material near the weld metal and the heat-affected zones transform through various metallurgical phases. Depending upon the chemistry of the metals in their areas. Hardening occurs in various degrees, depending mainly upon the carbon content. This is particularly very true in the heat – affected zone adjacent to the weld metal deposit. The resultant stresses are highest due to melting and solidification. Stress, due to welding is of magnitude roughly equal to the yield strength of the base material.
ii. Stress induced by machining
Machining induces stresses in parts. The bigger and more complex the part, the more stresses. These stresses can cause distortions in the part in long term. Cracking could occur and location changes causing parts to go out of tolerances. Stress Relieving heat treatment is used to reduce the stress that remain locked in a structure as a consequence of the various manufacturing processes. Stress Relieving, as the name implies, is designed to relieve these imposed stresses by reducing the hardness and increasing the ductility, and by these, reducing the danger of cracking in the weldment.
How is Stress Relieving Done?
Stress Relieving is done by uniformly heating- fabricated equipment or the vessel or vessel part to a sufficiently high temperature, but below the lower transformation temperature range, then subjecting it to a thermal retardation for a sufficient time depending upon the material thickness and then finally uniformly cooling it which is also of utmost importance.
Advantages of Post Weld Heat Treatment – Stress Relieving
- A much greater dimensional stability is obtained and maintained
- The potential of stress induce cracking is reduced.
- Metallurgical structure is improved.
- Strength of the Material and Life of the equipment is Enhanced.
Advantage of Refractory dry outs
- Improves refractory strength
- Eliminates refractory separation
- Removes water content
- Avoids thermal stress
